Products
Transformers, Switchgear & Circuit Breakers
High-voltage main power, dry-type, oil-immersed, pole-mounted, pad-mounted and custom transformers, plus switchgear and high-voltage circuit breakers.
345 kV and above Three-Phase Oil-Immersed Power Transformer
Oil-immersed Transformer

345 kV and above Three-Phase Oil-Immersed Power Transformer

Primary Voltage: 345kV and above (345 / 400 / 500kV optional)
Secondary Voltage: 6 / 10 / 11 / 33 / 35 kV
Cooling: ONAN / ONAF / KNAN / KNAF
IP class: IP54
Oil type: Mineral oil / FR3
Frequency: 50 / 60 Hz
Tap Range: OLTC / DETC
Vector Group: YNd11 / Dyn11 / Customized
Insulation class: Class A
Core material: Cold-rolled grain-oriented silicon steel
Service condition: Outdoor
Winding: Copper conductor
Standard: IEC 60076, IEEE C57 series
Lead time: 4 months
Prefabricated Compact Outdoor Substation
Packaged Transformer Substation

Prefabricated Compact Outdoor Substation

HV Rated Voltage: 110 / 132 / 345 kV and above, customized
LV Rated Voltage: 6 / 10 / 11 / 33 / 35 kV
Rated Capacity: Customized per customer’s requirement
Frequency: 50 / 60 Hz
Main transformer: 3-phase oil immersed power transformer
Transformer cooling: ONAN / ONAF / KNAN / KNAF
IP class: IP54
Insulation class: Class A
Transformer core: Cold-rolled grain-oriented silicon steel
Configuration: HV switchgear, power transformer, LV switchgear, protection & control, auxiliary supply, cable compartment
Switchgear option: GIS or AIS
Protection: Differential, overcurrent, earth fault, SCADA communication, fault recorder
Auxiliary system: Ventilation, interior lighting, anti-condensation heater, fire detection, fire suppression, earthing
Application: Outdoor installation
Up to 35 kV Single Phase Pole-Mounted Transformer
Pole-munted Transformer

Up to 35 kV Single Phase Pole-Mounted Transformer

Cooling：ONAN
IP class：IP55
Oil type：Mineral oil
Frequency：50 / 60 Hz
Tap Range：±2×2.5%（DETC）
Environment：Outdoor pole-mounted
Phase: Single phase
Winding material: Copper/Aluminum
Core material: Cold-rolled grain-oriented silicon steel
Primary Voltage: 12.47 / 13.2 / 13.8 / 19.9 / 20 / 22 / 24.9 / 33 / 34.5 kV
Insulation class: Class A
Secondary Voltage: 120 / 220 / 230 / 240 / 380 / 400 / 415 / 480 V
Dead-Tank SF₆ Circuit Breaker
Circuit Breaker

Dead-Tank SF₆ Circuit Breaker

Rated voltage: 40.5/ 72.5/ 126/ 145/ 252/ 363/ 420/ 550/ 800kV
Rated frequency: 50 Hz /60 Hz
Rated current: 4000 A / 5000 A
Rated short-circuit breaking current: 63 kA
Short-time withstand current: 63 kA, 3 s
Peak withstand current: 171 kA
Interrupter: Single-break puffer type
Operating mechanism: Disc spring hydraulic, phase-separated operation
Operating sequence: O‑0.3s‑CO‑3min‑CO
Mechanical endurance: 10,000 operations (Class M2)
Electrical endurance: 20 full-capacity breaking @63 kA
SF₆ filling pressure @20℃: 0.6 MPa(g)
SF₆ annual leak rate: ≤0.5%
Ambient temperature: -30℃ ~ +40℃
Altitude: ≤2000 m
Features: Built-in tank CT; porcelain / composite bushing optional
Station Class Transformer
Oil-immersed Transformer

Station Class Transformer

Cooling: ONAN / ONAF/KNAN/KNAF
IP class: IP54
Oil type: Mineral oil / FR3
Frequency: 50 / 60 Hz
Tap Range: ±2×2.5%(DETC)
Environment: Outdoor
Vector Group: Dyn11
Core material: Cold-rolled grain-oriented silicon steel
Primary Voltage: 10kV / 20kV / 35kV / 66kV / 110kV
Insulation class: Class A
Secondary Voltage: 0.4kV
110 kV Three Phase Oil-Immersed Power Transformer
Oil-immersed Transformer

110 kV Three Phase Oil-Immersed Power Transformer

Cooling：ONAN / ONAF/KNAN/KNAF
IP class：IP54
Oil type：Mineral oil / FR3
Frequency：50 / 60 Hz
Tap Range：±8 × 1.25% (OLTC)
Environment：Outdoor
Vector Group：YNd11/Dyn1
Core material：Cold-rolled grain-oriented silicon steel
Primary Voltage：110 / 115 / 132 kV
Insulation class：Class A
Secondary Voltage：6 / 10 / 11 / 33 / 35 kV
Lead time: 3 month
Application
Engineered for Every Operating Environment
Custom transformer solutions designed for different environments and finished to IEEE, CSA, ANSI, UL and other major international standards.
  • High Voltage Power Station
    High Voltage Power Station
  • Smart City Infrastructure
    Smart City Infrastructure
  • Solar/Wind Farm Collector Stations
    Solar/Wind Farm Collector Stations
  • Heavy Industry
    Heavy Industry
Who We Are?
Your Integrated Power System Solution Partner
Jiangsu ACME Power Co., Ltd. is a professional designer and global supplier of power system solutions, specializing in power transformers. We provide high-voltage main power, dry-type, oil-immersed, pole-mounted, pad-mounted, and custom transformers, switchgear, and high-voltage circuit breakers.

With stable monthly capacity, fast response, IEEE/CSA/ANSI/UL compliance, global engineering and after-sales teams, and annual export value of USD 40 million, we deliver reliable and customized power solutions worldwide.
Who We Are?
0 +
Distribution Transformers / Month
0 +
Working Days Quotation Turnaround
0 +
Million USD Annual Export Value
0 +
Year Warranty Coverage
After-sales
Transformers, Switchgear & Circuit Breakers
High-voltage main power, dry-type, oil-immersed, pole-mounted, pad-mounted and custom transformers, plus switchgear and high-voltage circuit breakers.
  • 01 Stable Production Capacity Stable monthly output ensures large-volume delivery.
    With a broad supplier network and monthly output of 300 distribution transformers and 10 power transformers, we reliably fulfill large-volume orders on time.
  • 02 Fast Response Efficiency Quotes 2–3 days, drawings 7 days.
    We provide quotations within 2–3 working days after inquiry and deliver outline and nameplate drawings within 7 working days, ensuring swift project progress.
  • 03 Certified Quality & Competitive Pricing Certified quality, competitive global pricing.
    Our products comply with IEEE, CSA, ANSI, and UL standards and are offered with a highly competitive pricing structure for all global markets.
  • 04 Global After-Sales & Warranty Global after-sales, 3–5 year warranty.
    Our North America after-sales team offers on-site installation guidance, field testing, and full lifecycle support, with 3-year or 5-year warranty coverage available.
  • 05 Full-Process Traceability Full photo documentation ensures traceability.
    All production stages are documented with photos, and complete project documentation is supplied upon completion for every order, ensuring full quality traceability.
  • 06 Export Performance USD 40 million annual export value.
    We possess rich export experience with an annual output value of 40 million US dollars, serving customers and projects across global markets.
  • 01 Stable Production Capacity Stable monthly output ensures large-volume delivery.
    With a broad supplier network and monthly output of 300 distribution transformers and 10 power transformers, we reliably fulfill large-volume orders on time.
  • 02 Fast Response Efficiency Quotes 2–3 days, drawings 7 days.
    We provide quotations within 2–3 working days after inquiry and deliver outline and nameplate drawings within 7 working days, ensuring swift project progress.
  • 03 Certified Quality & Competitive Pricing Certified quality, competitive global pricing.
    Our products comply with IEEE, CSA, ANSI, and UL standards and are offered with a highly competitive pricing structure for all global markets.
  • 04 Global After-Sales & Warranty Global after-sales, 3–5 year warranty.
    Our North America after-sales team offers on-site installation guidance, field testing, and full lifecycle support, with 3-year or 5-year warranty coverage available.
  • 05 Full-Process Traceability Full photo documentation ensures traceability.
    All production stages are documented with photos, and complete project documentation is supplied upon completion for every order, ensuring full quality traceability.
  • 06 Export Performance USD 40 million annual export value.
    We possess rich export experience with an annual output value of 40 million US dollars, serving customers and projects across global markets.
